Surface mounted LED display screen potting adhesive

Mainly used for automatic sealing of white surface mounted display screens, it plays a role in bonding, sealing, waterproofing, and moisture resistance.

Usage and precautions:

Due to the presence of fillers and thermal conductive materials in colloids, long-term storage of colloids may result in layering and sedimentation of fillers. Before use, mix the A/B components evenly before placing them in a mixing tank at a mass ratio of 10:1.

Pour the mixed adhesive into the device that needs to be sealed. Generally, vacuum defoaming is not necessary. If conditions permit, it is recommended to vacuum defoam before pouring. This product is room temperature curing type. The curing speed of adhesive is not closely related to the curing temperature, but to the proportion and content of B agent. The larger the B agent, the faster the curing speed (it is recommended to adjust the range of B agent from 100:7-100:12). At room temperature, it usually takes about 24 hours for initial curing, and after 72 hours, it is basically completely cured.

Unused adhesive should be stored in a sealed container. The storage period is 6 months (25 ℃). The mixed adhesive should be used up at once to avoid waste.

This product is non hazardous, but should not be ingested or seen.

Transportation: There are no regulations for domestic (CN-GB) or international (IMO, IATA, UN) transportation. Belonging to non dangerous goods.

Packaging specifications:

22Kg/group

CS-9809W-T20 sealant is a two-component silicone sealant with the following characteristics:

The A component of this product is a white viscous liquid, while the B component is a slightly yellow semi transparent or transparent liquid. The two components can be stored for a long time before mixing.

This product has good fluidity, adhesion, insulation, elasticity, corrosion resistance, weather resistance and other characteristics. After solidification, the colloid can be used over a wide temperature range. During the curing process, ethanol molecules are released, which will not corrode materials such as PC (Poly carbonate), PP, ABS, PVC, copper wire, etc. Good adhesion to most electronic component materials (except PP and PE).

＊ It does not shrink during curing, and has good waterproof, moisture-proof and anti-aging properties.

Compliant with the EU ROHS directive requirements.
