CS-874 single component room temperature cured silicone rubber series

Mainly used for fixing, shock absorption, sealing, waterproofing, bonding, insulation and other functions in electronic and electrical products. Such as small white goods, switching power supplies, transformers, circuit boards, network transformers, etc.

Clean the construction surface thoroughly, cut off the top of the nozzle according to the amount used, seal it on the packaging mouth, apply it to the construction surface, and place it in the air. The surface of this product will lose its stickiness (surface dryness) after 10-30 minutes at room temperature, and it will completely cure within 8-24 hours. Heating this product cannot significantly change its curing speed.

Unused adhesive should be stored in a sealed container. The storage period is 6 months (25 ℃).

This product is non hazardous, but should not be ingested or seen.

Transportation: There are no regulations for domestic (CN-GB) or international (IMO, IATA, UN) transportation. Belonging to non dangerous goods.

Before curing: ① Appearance: semi transparent paste/non flowing ② Product type: condensation type ③ Viscosity surface drying time (min, 25 ℃): 5-20 ④ Relative specific gravity: 1.55 ± 0.05

Operational performance: ① Surface skinning time (min, 25 ℃): 10-30 ② Curing time (min, 25 ℃): 8-48 hours (3-5mm) ③ Curing time (min, 80 ℃)

After curing: ① Hardness (shore A): 20-30 ② Thermal conductivity [W (m · K)] ③ Dielectric strength (kV/mm): ≥ 18-25 ④ Dielectric constant (100MHz): 2.55

⑤ Volume resistivity (Ω· cm): ≥ 2.5 × 1014 ⑥ Elongation at break (%): 130-170 ⑦ Dissipation factor (100Hz): 0.0022

⑧ Temperature range for use (℃): -55 ℃ -250 ℃ ⑨ Flame retardant grade: 94V1-94V0

CS-874 single component room temperature cured silicone rubber has the following characteristics:

This product is a single component organic silicon compound, which is a semi transparent paste.

This product has good high and low temperature resistance, earthquake resistance, flame retardancy, corona resistance, anti leakage insulation, corrosion resistance, weather resistance and other characteristics. After solidification, the colloid can be used over a wide temperature range.

During the curing process, it does not shrink and has good waterproof, moisture-proof, and insulating properties.

Compliant with the EU ROHS directive requirements.
